Case W7 Loader Service Manual

• Covers Case W7 Loader Backhoe (4WD)
• P/N 9-76762
• 770 pages
• Downloadable PDF format
• 236mb file size
• Works with Windows/Mac/Tablet/Mobile

The Case W7 service manual in downloadable PDF format includes over 500 pages of technical specifications, step-by-step instructions, illustrations and schematics to guide mechanics through mechanical, electrical and hydraulic repairs. The service manual was digitally reproduced from the original dealer manual into a clear, searchable PDF and is ideal for mechanics repairing or overhauling the Case W7 loader/backhoe. In addition to all machine systems, gas and diesel engine/fuel repair information is included. This manual can be downloaded after checkout to your computer, tablet or smartphone.

Latest edition.

Topics:

GENERAL INFORMATION

• Engine Specifications

ENGINE

• Cylinder Head, Diesel
• Cylinder Head, Gas
• Assemblies in Engine Block
• Front Mounted Oil Pump
• Engine Counter Balancer
• Water Pump
• Spark Ignition Governor
• Governor Linkage
• Fuel Injector, Diesel
• Carburetor Gas

HYDRAULICS·

• Hydraulic Cylinders
• Hydraulic Valves (2 or 3 Spool)
• Hydraulic Pump

STEERING

• Power Steering
• Power Steering Pump

POWER TRAIN

• Torque Converter
• Transmission
• Differential
• Planetaries and Axles
• Supplement

BRAKES

• Brake Cylinder, Shoes and Drum
• Transmission Cut-Out Valve
• Hydrovac Brake System

ELECTRICAL SYSTEM

• Alternator
• Starter
• Wiring Diagram

MOUNTED EQUIPMENT

• Model 32 Backhoe
• Model 33 and 34 Backhoe

Example from one of our manuals (actual manual contents may vary):

Need more information on this product?

If you have any questions regarding this manual, please contact us and reference the title or SKU.
