Ford BSD BSG Gas/Diesel Engine Service Manual

• Covers Ford BSD, BSG Gas and Diesel Engines (3, 4, 6 Cyl.)
  • BSG 326 (158 CID)
  • BSG 333 (201 CID)
  • BSD 326 (158 CID)
  • BSD 329 (175 CID)
  • BSD 333 (201 CID)
  • BSD 442 (256 CID)
  • BSD 442T (256 CID)
  • BSD 666 (401 CID)
  • BSD 666T (401 CID)
• 138 pages
• Downloadable PDF format
• Bookmarked, searchable, printable
• 70mb file size
• Works with PC/Mac/iPad/Tablet

The Ford BSD and BSG service manual includes specifications, step-by-step instructions and accurate illustrations to aid mechanics with service, repair and engine overhaul procedures. The complete service manual was carefully reproduced from the factory dealer manual and is a must for mechanics repairing or rebuilding the engine to the manufacturer’s standards.

Topics:

ENGINE

• Identification
• Description
• Diagnosis & Testing
• Overhaul
• Cleaning & Inspection
• Disassembly & Assembly

IGNITION SYSTEM

• Identification
• Description & Operation
• Diagnosis & Testing
• Adjustments
• Removal & Installation
• Cleaning & Inspection

FUEL AND TURBOCHARGER SYSTEM

• Identification
• Description & Operation
• Adjustments
• Disassembly & Assembly
• Diagnosis & Testing
• Diesel Fuel Systems Description
• Fuel Lines
• Fuel Filter
• Distribution Type Field Injection Pump
• In-Line Type Fuel Injection Pump
• Injectors
• Diagnosis & Testing
• Turbocharger

STARTER

• Description & Operation
• System Components
• 4.5 in Gasoline Engine Starter Operation
• 4.5 in & 5.0 in Diesel Engine Starter Operation
• Diagnosis & Testing
• Starter Removal & Installation
• Overhaul
• 4.5 in Gasoline Engine Starter
• 4.5 in & 5.0 in Diesel Engine Starter
• Starting Motor Relay
• Starting System Troubleshooting

COOLING SYSTEM

• Description & Operation
• Diagnosis & Testing
• Adjustments
• Removal & Installation
• Cleaning & Inspection

SPECIFICATIONS

• General Specifications
• Torque Data
• Ignition Specifications
• Fuel System Specifications
• Starter Specifications
• Service Bulletin

Displacement
BSD 326 – 2.6 liter (3 cylinder) (158 CID)
BSD 329 – 2.9 liter (3 cylinder) (175 CID)
BSD 333 – 3.3 liter (3 cylinder) (201 CID)
BSD 442 -.4.2 liter (4 cylinder) (256 CID)
BSD 442T -. .4.2 liter (4 cylinder) (256 CID)
BSD 666 – 6.6 liter (6 cylinder) (401 CID)
BSD 666T – 6.6 liter (6 cylinder) (401 CID)
BSG 326 – 2.6 liter (3 cylinder) (158 CID)
BSG 333 -. 3.3 liter (3 cylinder) (201 CID)
BSD = Basildon Series: Diesel
BSG = Basildon Series: Gas
T = Turbocharged
